H-Beam Automatic Welding Machine

Name: HBeam Automatic Welding Machine
Brand: OLIVET
Price: 1 USD

Brand Name : OLIVET

Model Number : HBJ

MOQ : 1set

Price : pls confirm with us

Payment Terms : 30% TT in advance, 70% TT before the shipment

Supply Ability : as you want

Delivery Time : 30working days

Packaging Details : Mainframe naked, spare parts packed in case

Contact Now

H-Beam Automatic Welding Machine

There LHA gantry type, LHC cantilever type H-Beam Automatic Welding Machine and LHT double column-beam automatic welding machine.

It adopts A.C.inverter control, with functions of stable running and fast traveling speed; The seam-tracking arc-guide mechanism is three-spindle system to guarantee the alignment without aberrancy; The main frame and welding machine are intergrated control, with flux auto-recovering system and it is easy to operate with high efficiency.

LHT double column-beam automatic welding machine can weld two pieces of beam at the same time, and the web height of beam is not limited by main machine.

Applied flange width	200-800mm
Applied web height	200-1500mm
Beam length	4000-15000mm
Rail span	4000mm
Rail length	18000mm
Welding speed	120-1200mm/min
Welding position	Vessel position
Wire size	3.2－5mm
Flux recycling system	100kg*2
Main machine power	9Kw (excluding two SAW welders

you may also interested in other products

Contact Annie Zhang

Skype:Zhang.annie78

Tel:+86(510)83830908
Mobile:+86-13771100370

E-mail:sales@chinaolivet.cn

http://www.welding-rotators-com.ecer.com

China H-Beam Automatic Welding Machine factory

H-Beam Automatic Welding Machine Images
